Product specifications
Acoustic properties (core)
Thickness 50 mm
- An acoustic core 50 mm thick is required for damping down basstones and reducing the number of decibels
Density 80 kg/m³
- High density = lots of mass
- High density + thickness = our products are able to reduce all human sound frequencies by 100%
Finish
Aluminium frame
- Sturdy profiles of our own design
- 52 mm thick
- Powder-lacquered and so scratch-free
- Three colours available: RAL 9010 (warm white), RAL 9016 (traffic white) RAL 9006 (aluminium grey)
Clamps
- Covers can be stretched tight
- Covers are replaceable
Molton
- Covers the acoustic filling
- Provides a smooth, even effect
- Trevira CS quality
Tensioning fabric in Trevira CS
- Stable branded fibre
- 100% polyester
- Flame-retardant
- Not affected by variations in temperature humidity: cover remains stretched flat
Sublimation print
- Razor-sharp prints
- Longer colour-fastness
- Cover remains acoustically open (as opposed to inkjet print)
Technical properties
Acoustic value
NRC 0.95; α value 1
Fire class
Filling A1, canvas B-s1-d1
Weight
5kg/m²
Acoustic filling
Mix of stone wool and glass wool
Thickness
52 mm
Canvas
100% polyester (Trevira CS)
