ARTpanel

Maximum absorption on the wall

The ARTpanel is an acoustic wall panel that improves acoustics by reducing reverberations and unwanted noise reflections. This way, it increases speech intelligibility in the room.

Maximum sound absorption is ensured by the ARTpanel’s unique high-density acoustic filling. For this reason, it is the top-of-the-line acoustic panel on the market.

How the ARTpanel perfectly blends with the room

Our high-quality ARTpanels are custom-made in our workshop and then installed on-site by means of a wall bracket. The canvas and the aluminium frame can be customised with colours of your choice. For instance, you may want the ARTpanel to blend in with your interior. Do you prefer a canvas with a custom print or photo? In that case, we apply sublimation printing for a crystal clear result.

Product specifications
Technical properties Downloads
ARTpanel ARTpanel ARTpanel ARTpanel ARTpanel

Product specifications

Acoustic properties (core)

Thickness 50 mm

  • An acoustic core 50mm thick is required for damping down bass tones and reducing the number of decibels.

Density 80 kg/m3

  • High density = lots of mass
  • High density + thickness 5 cm = our products are able to diminish all human sound frequencies by 100%



Finish

Aluminium frame

  • Sturdy profiles of our own design
  • 57 mm thick
  • Powder-lacquered and so scratch-free
  • Four colours available: RAL 9010 (warm white), RAL 9016 (traffic white), RAL 9006 (aluminium grey), 7021 (black)

Clamps

  • Covers can be stretched tight
  • Covers are replaceable

Molton

  • Covers the acoustic filling
  • Provides a smooth, even effect
  • Trevira CS quality

End cover/tension in Trevira CS

  • Stable branded fibre
  • Not affected by variations in temperature and humidity: cover remains stretched flat
  • 100% polyester
  • Flame-retardant

Sublimation print

  • Razor-sharp prints
  • Longer colour fastness
  • Cover remains acoustically open (as opposed to inkjet print)

Technical properties

Acoustic value

NRC = 0.95; ╬▒ value 1

Fire class

Filling A1, canvas B-s1-d1

Weight

10 kg/m2

Thickness

Acoustic core of 50 mm, total panel thickness with frame = 57 mm

Acoustic filling

Mix of stone wool and glass wool

Canvas

100% polyester (Trevira CS)

Downloads

Measurement report
